Sunon
| Part Number | KDE1205PFVX.11.MS.A.GN | Manufacturer | Sunon |
|---|---|---|---|
| Description | FAN AXIAL 50X10MM 12VDC WIRE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 12486 pcs | Data sheet | 1.KDE1205PFVX.11.MS.A.GN.pdf2.KDE1205PFVX.11.MS.A.GN.pdf3.KDE1205PFVX.11.MS.A.GN.pdf |
| Width | 10.00mm | Weight | 0.044 lb (19.96g) |
| Voltage Range | 4.5 ~ 13.8VDC | Voltage - Rated | 12VDC |
| Termination | 2 Wire Leads | Static Pressure | 0.180 in H2O (44.8 Pa) |
| Size / Dimension | Square - 50mm L x 50mm H | Series | MagLev® KDE |
| RPM | 6100 RPM | Power (Watts) | 2.00W |
| Other Names | 259-1356 E1250PUX4A--GRG KDE1205PFVX 11.MS.A.GN KDE1205PFVX11MSAGN |
Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Noise | 35.0 dB(A) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Frame | Polybutylene Terephthalate (PBT) | Material - Blade | Polybutylene Terephthalate (PBT) |
| Manufacturer Standard Lead Time | 14 Weeks | Lifetime @ Temp. | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Features | - | Fan Type | Tubeaxial |
| Current Rating | 0.170A | Bearing Type | Vapo-Bearing™ |
| Approvals | CE, CUR, TUV, UL | Air Flow | 15.2 CFM (0.426m³/min) |
