Sunon
| Part Number | KDE1203PFB1-8(V) | Manufacturer | Sunon |
|---|---|---|---|
| Description | FAN AXIAL 30X10MM 12VDC WIRE | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 4994 pcs | Data sheet | 1.KDE1203PFB1-8(V).pdf2.KDE1203PFB1-8(V).pdf |
| Width | 10.00mm | Weight | 0.017 lb (7.71g) |
| Voltage Range | 10.2 ~ 13.8VDC | Voltage - Rated | 12VDC |
| Termination | 2 Wire Leads | Static Pressure | 0.140 in H2O (34.9 Pa) |
| Size / Dimension | Square - 30mm L x 30mm H | Series | KDE |
| RPM | 8000 RPM | Power (Watts) | 900mW |
| Other Names | 259-1018 E1230PFH18---VE KDE1203PFB1-8V KDE1203PFB18V |
Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Noise | 27.0 dB(A) | Material - Frame | Polybutylene Terephthalate (PBT) |
| Material - Blade | Polybutylene Terephthalate (PBT) | Lifetime @ Temp. | - |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Ingress Protection | - |
| Features | Locked Rotor Protection | Fan Type | Tubeaxial |
| Current Rating | 0.080A | Bearing Type | Ball |
| Approvals | CE, CUR, TUV, UL | Air Flow | 5.1 CFM (0.143m³/min) |
