Panasonic
| Part Number | S4EB-5V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY GEN PURPOSE SPST X 4 4A 5V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5798 pcs | Data sheet | S4EB-5V.pdf |
| Turn On Voltage (Max) | 3.5 VDC | Turn Off Voltage (Min) | 0.5 VDC |
| Termination Style | PC Pin | Switching Voltage | 250VAC, 48VDC - Max |
| Series | S | Release Time | 10ms |
| Relay Type | General Purpose | Packaging | Tube |
| Other Names | 255-2252 S4EB-5V-ND S4EB5V |
Operating Temperature | -55°C ~ 65°C |
| Operate Time | 15ms | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 10 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Features | Sealed - Amber |
| Detailed Description | General Purpose Relay SPST-NO (1 Form A) x 4 5VDC Coil Through Hole | Contact Rating (Current) | 4A |
| Contact Material | Silver Alloy, Cadmium Free | Contact Form | SPST-NO (1 Form A) x 4 |
| Coil Voltage | 5VDC | Coil Type | Non Latching |
| Coil Resistance | 130 Ohms | Coil Power | 192 mW |
| Coil Current | 38.5mA |
