NMB Technologies Corp.
| Part Number | 3108NL-05W-B10-P00 | Manufacturer | NMB Technologies Corp. |
|---|---|---|---|
| Description | FAN AXIAL 80X20MM 24VDC WIRE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 8858 pcs | Data sheet | 1.3108NL-05W-B10-P00.pdf2.3108NL-05W-B10-P00.pdf3.3108NL-05W-B10-P00.pdf |
| Width | 20.00mm | Weight | 0.187 lb (84.82g) |
| Voltage Range | 15 ~ 27.6VDC | Voltage - Rated | 24VDC |
| Termination | 2 Wire Leads | Static Pressure | 0.084 in H2O (20.9 Pa) |
| Size / Dimension | Square - 80mm L x 80mm H | Series | 3108NL |
| RPM | 2350 RPM | Power (Watts) | 1.30W |
| Other Names | 08020MA-24J-EA-00 3108NL05WB10P00 P12838 |
Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Noise | 26.0 dB | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Frame | Plastic | Material - Blade | Plastic |
| Manufacturer Standard Lead Time | 14 Weeks | Lifetime @ Temp. | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Features | - | Fan Type | Tubeaxial |
| Current Rating | 0.050A | Bearing Type | Ball |
| Approvals | CE, CSA, UL, VDE | Air Flow | 26.5 CFM (0.742m³/min) |
