2N3700UB

Microsemi

Image may be representation. See specifications for product details.

Product Overview

Part Number:	2N3700UB
Manufacturer/Brand:	Microsemi
Product description	TRANS NPN 80V 1A UB
Datasheets:	2N3700UB.pdf
RoHs Status	Contains lead / RoHS non-compliant
Stock Condition	5161 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 5161 pcs

Reference Price (In US Dollars)

1 pcs: $6.549

10 pcs: $5.955

25 pcs: $5.508

100 pcs: $5.062

250 pcs: $4.615

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$6.549

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 2N3700UB

Part Number	2N3700UB	Manufacturer	Microsemi
Description	TRANS NPN 80V 1A UB	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	5161 pcs	Data sheet	2N3700UB.pdf
Voltage - Collector Emitter Breakdown (Max)	80V	Vce Saturation (Max) @ Ib, Ic	500mV @ 50mA, 500mA
Transistor Type	NPN	Supplier Device Package	UB
Series	-	Power - Max	500mW
Packaging	Bulk	Package / Case	3-SMD, No Lead
Operating Temperature	-65°C ~ 200°C (TJ)	Mounting Type	Surface Mount
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	8 Weeks
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant	Frequency - Transition	-
Detailed Description	Bipolar (BJT) Transistor NPN 80V 1A 500mW Surface Mount UB	DC Current Gain (hFE) (Min) @ Ic, Vce	50 @ 500mA, 10V
Current - Collector Cutoff (Max)	10µA (ICBO)	Current - Collector (Ic) (Max)	1A
