Hirose
| Part Number | BM22L-4P-V(53) | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN HDR 4POS SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 92612 pcs | Data sheet | 1.BM22L-4P-V(53).pdf2.BM22L-4P-V(53).pdf3.BM22L-4P-V(53).pdf |
| Voltage Rating | 50V | Termination | Solder |
| Style | Board to Board | Shrouding | Shrouded - 4 Wall |
| Series | BM22 | Row Spacing - Mating | - |
| Pitch - Mating | - | Packaging | Cut Tape (CT) |
| Overall Contact Length | - | Other Names | H122449CT |
| Operating Temperature | -35°C ~ 85°C | Number of Rows | - |
| Number of Positions Loaded | All | Number of Positions | 4 (2 + 2 Power) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | 0.9mm |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Liquid Crystal Polymer (LCP) | Insulation Height | 0.030" (0.75mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | - | Fastening Type | Friction Lock |
| Detailed Description | Connector Header Surface Mount 4 (2 + 2 Power) position | Current Rating | - |
| Contact Type | Outer Shroud Contact | Contact Shape | - |
| Contact Material | Copper Alloy | Contact Length - Post | - |
| Contact Length - Mating | - | Contact Finish Thickness - Post | Flash |
| Contact Finish Thickness - Mating | 2.00µin (0.051µm) | Contact Finish - Post | Gold |
| Contact Finish - Mating | Gold | Connector Type | Header |
| Applications | - |
