M50-3610642R

Harwin

Image may be representation. See specifications for product details.

Product Overview

Part Number:	M50-3610642R
Manufacturer/Brand:	Harwin
Product description	CONN HDR 1.27MM SMD AU 12POS
Datasheets:	1.M50-3610642R.pdf 2.M50-3610642R.pdf 3.M50-3610642R.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	63854 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 63854 pcs

Reference Price (In US Dollars)

1 pcs: $0.596

10 pcs: $0.542

100 pcs: $0.465

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.596

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of M50-3610642R

Part Number	M50-3610642R	Manufacturer	Harwin
Description	CONN HDR 1.27MM SMD AU 12POS	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	63854 pcs	Data sheet	1.M50-3610642R.pdf 2.M50-3610642R.pdf 3.M50-3610642R.pdf
Voltage Rating	250V	Termination	Solder
Style	Board to Board or Cable	Shrouding	Unshrouded
Series	Archer M50	Row Spacing - Mating	0.050" (1.27mm)
Pitch - Mating	0.050" (1.27mm)	Packaging	Cut Tape (CT)
Overall Contact Length	-	Other Names	952-3091-1
Operating Temperature	-55°C ~ 105°C	Number of Rows	2
Number of Positions Loaded	All	Number of Positions	12
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	3.9mm, 5.3mm, 6.08mm, 6.18mm, 7mm
Manufacturer Standard Lead Time	7 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Insulation Material	Thermoplastic	Insulation Height	0.039" (1.00mm)
Insulation Color	Black	Ingress Protection	-
Features	Board Guide, Pick and Place	Fastening Type	Push-Pull
Detailed Description	Connector Header Surface Mount 12 position 0.050" (1.27mm)	Current Rating	1A
Contact Type	Male Pin	Contact Shape	Square
Contact Material	Brass	Contact Length - Post	-
Contact Length - Mating	0.118" (3.00mm)	Contact Finish Thickness - Post	80.0µin (2.03µm)
Contact Finish Thickness - Mating	1.00µin (0.025µm)	Contact Finish - Post	Tin
Contact Finish - Mating	Gold	Connector Type	Header
Applications	-
