EPCOS
| Part Number | B65811J0000R030 | Manufacturer | EPCOS |
|---|---|---|---|
| Description | FERRITE CORE RM 5.7UH N30 2PCS | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 57759 pcs | Data sheet | B65811J0000R030.pdf |
| Width | 11.00mm | Tolerance | -20%, +30% |
| Supplier Device Package | RM 8 | Series | B65811 |
| Other Names | 495-5257 B65811J R 30 B65811JR30 B65811JR30-ND |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Minimum Core Cross Section (Amin) mm² | 55 | Material | N30 |
| Manufacturer Standard Lead Time | 24 Weeks | Length | 23.20mm |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Initial Permeability (µi) | 4300 |
| Inductance Factor (Al) | 5.7µH | Height | 8.25mm |
| Gap | Ungapped | Finish | Uncoated |
| Effective Permeability (µe) | 2690 | Effective Magnetic Volume (Ve) mm³ | 2430 |
| Effective Length (le) mm | 38 | Effective Area (Ae) mm² | 64 |
| Diameter | - | Core Type | RM |
| Core Factor (ΣI/A) mm1 | 0.59 |
