PQ2614BHA-150K

Bourns, Inc.

Image may be representation. See specifications for product details.

Product Overview

Part Number:	PQ2614BHA-150K
Manufacturer/Brand:	Bourns, Inc.
Product description	FIXED IND 15UH 30A 1.9MOHM SMD
Datasheets:	PQ2614BHA-150K.pdf
RoHs Status	RoHS Compliant
Stock Condition	27090 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 27090 pcs

Reference Price (In US Dollars)

1 pcs: $1.391

25 pcs: $1.158

100 pcs: $0.834

500 pcs: $0.741

1000 pcs: $0.695

2500 pcs: $0.672

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$1.391

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of PQ2614BHA-150K

Part Number	PQ2614BHA-150K	Manufacturer	Bourns, Inc.
Description	FIXED IND 15UH 30A 1.9MOHM SMD	Lead Free Status / RoHS Status	RoHS Compliant
Quantity Available	27090 pcs	Data sheet	PQ2614BHA-150K.pdf
Type	Wirewound	Tolerance	±10%
Supplier Device Package	-	Size / Dimension	1.098" L x 0.780" W (27.90mm x 19.80mm)
Shielding	Shielded	Series	PQ2614BHA
RoHS Status	RoHS Compliant	Ratings	AEC-Q200
Q @ Freq	-	Packaging	Tray
Package / Case	Nonstandard	Operating Temperature	-40°C ~ 155°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material - Core	Ferrite	Manufacturer Standard Lead Time	13 Weeks
Inductance Frequency - Test	100kHz	Inductance	15µH
Height - Seated (Max)	0.630" (16.00mm)	Frequency - Self Resonant	12MHz
Features	-	Detailed Description	15µH Shielded Wirewound Inductor 30A 1.9 mOhm Max Nonstandard
DC Resistance (DCR)	1.9 mOhm Max	Current Rating	30A
Current - Saturation	14A
