1-1747147-5

Agastat Relays / TE Connectivity

Image may be representation. See specifications for product details.

Product Overview

Part Number:	1-1747147-5
Manufacturer/Brand:	Agastat Relays / TE Connectivity
Product description	DZ5200 REC ASSY 3P 5.08MM PITCH
Datasheets:	1-1747147-5.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	9584 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 9584 pcs

Reference Price (In US Dollars)

750 pcs: $3.303

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$3.303

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 1-1747147-5

Part Number	1-1747147-5	Manufacturer	Agastat Relays / TE Connectivity
Description	DZ5200 REC ASSY 3P 5.08MM PITCH	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	9584 pcs	Data sheet	1-1747147-5.pdf
Voltage Rating	250V	Termination	Solder
Style	Board to Board	Series	Dynamic DZ5200
Row Spacing - Mating	-	Pitch - Mating	0.200" (5.08mm)
Packaging	Tube	Other Names	A120275
Operating Temperature	-55°C ~ 105°C	Number of Rows	1
Number of Positions Loaded	All	Number of Positions	5
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	-
Manufacturer Standard Lead Time	18 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Insulation Material	Polyester, Glass Filled	Insulation Height	0.551" (14.00mm)
Insulation Color	Black	Ingress Protection	-
Features	Board Guide, Board Lock	Fastening Type	Push-Pull
Detailed Description	5 Position Receptacle Connector Through Hole Gold	Current Rating	20A
Contact Type	Female Blade Socket	Contact Shape	Rectangular
Contact Material	Phosphor Bronze	Contact Length - Post	0.150" (3.81mm)
Contact Finish Thickness - Post	78.7µin (2.00µm)	Contact Finish Thickness - Mating	8.00µin (0.203µm)
Contact Finish - Post	Tin	Contact Finish - Mating	Gold
Connector Type	Receptacle	Applications	-
