0901310799

Affinity Medical Technologies - a Molex company

Image may be representation. See specifications for product details.

Product Overview

Part Number:	0901310799
Manufacturer/Brand:	Affinity Medical Technologies - a Molex company
Product description	CONN HEADER 78POS .100 STR GOLD
Datasheets:	0901310799.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	15898 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 15898 pcs

Reference Price (In US Dollars)

2800 pcs: $1.972

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$1.972

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 0901310799

Part Number	0901310799	Manufacturer	Affinity Medical Technologies - a Molex company
Description	CONN HEADER 78POS .100 STR GOLD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	15898 pcs	Data sheet	0901310799.pdf
Voltage Rating	-	Termination	Solder
Style	Board to Cable/Wire	Shrouding	Unshrouded
Series	C-Grid III 90131	Row Spacing - Mating	0.100" (2.54mm)
Pitch - Mating	0.100" (2.54mm)	Packaging	Bulk
Overall Contact Length	0.478" (12.15mm)	Other Names	090131-0799 90131-0799 901310799
Operating Temperature	-	Number of Rows	2
Number of Positions Loaded	All	Number of Positions	78
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	-
Manufacturer Standard Lead Time	15 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Insulation Material	Polyester, Glass Filled	Insulation Height	0.098" (2.50mm)
Insulation Color	Black	Ingress Protection	-
Features	-	Fastening Type	Push-Pull
Detailed Description	Connector Header Through Hole 78 position 0.100" (2.54mm)	Current Rating	-
Contact Type	Male Pin	Contact Shape	Square
Contact Material	Brass	Contact Length - Post	0.114" (2.90mm)
Contact Length - Mating	0.266" (6.75mm)	Contact Finish Thickness - Post	118.1µin (3.00µm)
Contact Finish Thickness - Mating	15.0µin (0.38µm)	Contact Finish - Post	Tin
Contact Finish - Mating	Gold	Connector Type	Header, Breakaway
Applications	Automotive, General Purpose
