0026482156

Affinity Medical Technologies - a Molex company

Image may be representation. See specifications for product details.

Product Overview

Part Number:	0026482156
Manufacturer/Brand:	Affinity Medical Technologies - a Molex company
Product description	CONN BKWY HEADER 15POS R/A GOLD
Datasheets:	0026482156.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	21986 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 21986 pcs

Reference Price (In US Dollars)

1 pcs: $1.463

10 pcs: $1.405

25 pcs: $1.287

50 pcs: $1.229

100 pcs: $1.17

250 pcs: $1.024

500 pcs: $0.995

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:
Qty:

Total:$1.463

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of 0026482156

Part Number	0026482156	Manufacturer	Affinity Medical Technologies - a Molex company
Description	CONN BKWY HEADER 15POS R/A GOLD	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	21986 pcs	Data sheet	0026482156.pdf
Voltage Rating	-	Termination	Solder
Style	Board to Board or Cable	Shrouding	Shrouded - 1 Wall
Series	KK 41672	Row Spacing - Mating	-
Pitch - Mating	0.156" (3.96mm)	Packaging	Bulk
Overall Contact Length	-	Other Names	0026-48-2156 002648-2156 0026482156-ND 26-48-2156 26482156 WM50011-15 WM50011-2156 WM50011-2156-ND
Operating Temperature	-	Number of Rows	1
Number of Positions Loaded	All	Number of Positions	15
Mounting Type	Through Hole, Right Angle	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material Flammability Rating	UL94 V-0	Mated Stacking Heights	-
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Insulation Material	Polyester
Insulation Height	0.355" (9.02mm)	Insulation Color	Black
Ingress Protection	-	Features	-
Fastening Type	Friction Lock	Detailed Description	Connector Header Through Hole, Right Angle 15 position 0.156" (3.96mm)
Current Rating	-	Contact Type	Male Pin
Contact Shape	Square	Contact Material	Brass
Contact Length - Post	0.212" (5.38mm)	Contact Length - Mating	0.450" (11.43mm)
Contact Finish Thickness - Post	100.0µin (2.54µm)	Contact Finish Thickness - Mating	20.0µin (0.51µm)
Contact Finish - Post	Tin	Contact Finish - Mating	Gold
Connector Type	Header, Breakaway	Applications	Automotive, General Purpose, Industrial, Medical, Telecommunications
