Molex, LLC
| Part Number | 0022290104 | Manufacturer | Molex, LLC |
|---|---|---|---|
| Description | KK 100 HDR FRLK VERT 10POS TIN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 192218 pcs | Data sheet | 1.0022290104.pdf2.0022290104.pdf |
| Voltage - DC Spark Over (Nom) | - | Type Attributes | - |
| Termination | Solder | Style | Board to Board or Cable |
| Stacking Direction | Male Pin | Shrouding | 0.100" (2.54mm) |
| Shield Termination | Square | Series | KK® 42227 |
| Row Spacing - Mating | Shrouded - 1 Wall | RoHS Status | Bulk |
| Ripple Current - Low Frequency | Automotive, General Purpose, Medical, Telecommunications | Pitch - Connector | - |
| Overall Contact Length | 0.120" (3.05mm) | Other Names | 0022-29-0104 002229-0104 22-29-0104 22290104 42227-0591 |
| Operating Temperature | - | Number of Rows | 1 |
| Number of Positions | 10 | Number of Contacts | 100µin (2.54µm) |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Material - Insulation | 4 |
| Manufacturer Standard Lead Time | 10 Weeks | Manufacturer Part Number | 0022290104 |
| Length - Post (Mating) | - | Insulation Material | Tin |
| Insulation Height | 0.540" (13.72mm) | Features | - |
| Expanded Description | 10 Positions Header, Breakaway Connector 0.100" (2.54mm) Through Hole Tin | Description | KK 100 HDR FRLK VERT 10POS TIN |
| Current Rating | - | Current - Max/Contact | Friction Lock |
| Contact Length - Post | 0.295" (7.49mm) | Contact Length - Mating | - |
| Contact Finish Thickness - Post | Polyamide (PA), Nylon | Contact Finish Thickness - Mating | Tin |
| Contact Finish - Post | 100µin (2.54µm) | Contact Finish - Mating | 0.337" (8.56mm) |
| Connector Type | Header, Breakaway | Actual Diameter | Black |
