Weidmuller
| Part Number | 1789160000 | Manufacturer | Weidmuller |
|---|---|---|---|
| Description | CONN TERM BLOCK 3POS 5.08MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 65006 pcs | Data sheet | 1789160000.pdf |
| Wire Termination | Screw - Clamping Yoke, Tension Sleeve | Wire Gauge | 12-26 AWG |
| Voltage | 300V | Torque - Screw | 0.2-0.25 Nm (1.7-2.2 Lb-In) |
| Series | Omnimate LP | Screw Thread | - |
| Screw Material - Plating | - | Positions Per Level | 3 |
| Pitch | 0.200" (5.08mm) | Packaging | Bulk |
| Other Names | 1789160000-ND 281-2858 LP/5.08/3/90THR |
Operating Temperature | -50°C ~ 100°C |
| Number of Levels | 1 | Mounting Type | Through Hole |
| Mating Orientation | Horizontal with Board | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Housing Material | Polyamide (PA), Nylon |
| Features | Interlocking (Side) | Detailed Description | 3 Position Wire to Board Terminal Block Horizontal with Board 0.200" (5.08mm) Through Hole |
| Current | 20A | Contact Material - Plating | Copper Alloy - Tin Plated |
| Color | Black | Clamp Material - Plating | - |
