Sunon
| Part Number | SF23092A2092MBL.GN | Manufacturer | Sunon |
|---|---|---|---|
| Description | FAN AXIAL 91.5X25.5MM 220/240VAC | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3909 pcs | Data sheet | 1.SF23092A2092MBL.GN.pdf2.SF23092A2092MBL.GN.pdf |
| Width | 25.50mm | Weight | 0.617 lb (279.87g) |
| Voltage Range | - | Voltage - Rated | 240VAC |
| Termination | 2 Wire Leads | Static Pressure | 0.180 in H2O (44.8 Pa) |
| Size / Dimension | Square - 91.5mm L x 91.5mm H | Series | SF |
| RPM | 2700 RPM | Power (Watts) | 14.00W |
| Other Names | 259-1982 SF23092A-2092MBL.GN SF23092A2092MBL.GN-ND |
Operating Temperature | - |
| Noise | 38.0 dB(A) | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Frame | Aluminum | Material - Blade | - |
| Manufacturer Standard Lead Time | 14 Weeks | Lifetime @ Temp. | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Features | - | Fan Type | Tubeaxial |
| Current Rating | 0.070A | Bearing Type | Ball |
| Approvals | CE, CUR, TUV, UL | Air Flow | 35.0 CFM (0.980m³/min) |
