Souriau Connection Technology
| Part Number | JMXHH1G08FSUDSU | Manufacturer | Souriau Connection Technology |
|---|---|---|---|
| Description | CONN RCPT FMALE 8POS SOLDER CUP | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4148 pcs | Data sheet | 1.JMXHH1G08FSUDSU.pdf2.JMXHH1G08FSUDSU.pdf3.JMXHH1G08FSUDSU.pdf |
| Voltage Rating | 100V | Termination | Solder Cup |
| Shielding | Unshielded | Shell Size, MIL | - |
| Shell Size - Insert | 1-8 | Shell Material | Polyetherimide (PEI) |
| Shell Finish | - | Series | JMX |
| Packaging | Bulk | Other Names | SOU2260 |
| Orientation | G | Operating Temperature | -20°C ~ 100°C |
| Number of Positions | 8 | Mounting Type | Panel Mount |
| Mounting Feature | Bulkhead - Rear Side Nut | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insert Material | Polyetheretherketone (PEEK) | Ingress Protection | IP68 - Dust Tight, Waterproof |
| Features | - | Fastening Type | Push-Pull |
| Detailed Description | 8 Position Circular Connector Receptacle, Female Sockets Solder Cup Gold | Current Rating | 5A |
| Contact Material | Copper Nickel | Contact Finish Thickness - Mating | 19.7µin (0.50µm) |
| Contact Finish - Mating | Gold | Connector Type | Receptacle, Female Sockets |
| Color | Light Gray | Cable Opening | - |
| Backshell Material, Plating | - | Applications | Industrial, Instrumentation, Medical |
