PC6N139X

Sharp Microelectronics

Image may be representation. See specifications for product details.

Product Overview

Part Number:	PC6N139X
Manufacturer/Brand:	Sharp Microelectronics
Product description	OPTOISO 2.5KV DARL W/BASE 8-DIP
Datasheets:	PC6N139X.pdf
RoHs Status	Contains lead / RoHS non-compliant
Stock Condition	5786 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

Download Product Details PDF

In Stock 5786 pcs

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:Info@infinite-electronic.hk

Target Price:
Qty:

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of PC6N139X

Part Number	PC6N139X	Manufacturer	Sharp Microelectronics
Description	OPTOISO 2.5KV DARL W/BASE 8-DIP	Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant
Quantity Available	5786 pcs	Data sheet	PC6N139X.pdf
Voltage - Output (Max)	18V	Voltage - Isolation	2500Vrms
Voltage - Forward (Vf) (Typ)	1.5V	Vce Saturation (Max)	-
Turn On / Turn Off Time (Typ)	300ns, 1.5µs	Supplier Device Package	8-DIP
Series	-	Rise / Fall Time (Typ)	-
Packaging	Tube	Package / Case	8-DIP (0.300", 7.62mm)
Output Type	Darlington with Base	Other Names	425-1801-5
Operating Temperature	0°C ~ 70°C	Number of Channels	1
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Lead Free Status / RoHS Status	Contains lead / RoHS non-compliant	Input Type	DC
Detailed Description	Optoisolator Darlington with Base Output 2500Vrms 1 Channel 8-DIP	Current Transfer Ratio (Min)	400% @ 0.5mA
Current Transfer Ratio (Max)	-	Current - Output / Channel	60mA
Current - DC Forward (If) (Max)	20mA
