DS1-30-0003

Schurter

Image may be representation. See specifications for product details.

Product Overview

Part Number:	DS1-30-0003
Manufacturer/Brand:	Schurter
Product description	COMMON MODE CHOKE 3.15A 2LN TH
Datasheets:	DS1-30-0003.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	8894 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 8894 pcs

Reference Price (In US Dollars)

1 pcs: $3.392

50 pcs: $2.869

100 pcs: $2.452

500 pcs: $2.139

1000 pcs: $1.93

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$3.392

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of DS1-30-0003

Part Number	DS1-30-0003	Manufacturer	Schurter
Description	COMMON MODE CHOKE 3.15A 2LN TH	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	8894 pcs	Data sheet	DS1-30-0003.pdf
Voltage Rating - DC	600V	Voltage Rating - AC	-
Size / Dimension	1.181" L x 1.181" W (30.00mm x 30.00mm)	Series	DS
Ratings	-	Packaging	Bulk
Package / Case	Radial - 4 Leads	Other Names	486-3098 DS1-30-0003-ND DS1-30-3.15-150/A
Operating Temperature	-40°C ~ 125°C	Number of Lines	2
Mounting Type	Through Hole	Moisture Sensitivity Level (MSL)	Not Applicable
Manufacturer Standard Lead Time	12 Weeks	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height (Max)	0.591" (15.00mm)	Filter Type	-
Features	-	Detailed Description	2 Line Common Mode Choke Through Hole 3.15A DCR 55 mOhm
DC Resistance (DCR) (Max)	55 mOhm	Current Rating (Max)	3.15A
Approvals	-
