Schaffner EMC, Inc.
| Part Number | RD7127-6-25M0 | Manufacturer | Schaffner EMC, Inc. |
|---|---|---|---|
| Description | COMMON MODE CHOKE 25MH 6A 2LN TH | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4726 pcs | Data sheet | RD7127-6-25M0.pdf |
| Voltage Rating - DC | 850V | Voltage Rating - AC | 600V |
| Size / Dimension | 2.756" L x 2.756" W (70.00mm x 70.00mm) | Series | RD |
| Ratings | - | Packaging | Tray |
| Package / Case | Horizontal, 4 PC Pin | Other Names | 292-139 800659 817-2023 RD7127-6-25M0-ND |
| Operating Temperature | -25°C ~ 110°C | Number of Lines | 2 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 10 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Inductance @ Frequency | 25mH @ 400Hz | Height (Max) | 1.594" (40.50mm) |
| Filter Type | Power Line | Features | - |
| Detailed Description | 25mH @ 400Hz 2 Line Common Mode Choke Through Hole 6A (Typ) DCR 84.2 mOhm (Typ) | DC Resistance (DCR) (Max) | 84.2 mOhm (Typ) |
| Current Rating (Max) | 6A (Typ) | Approvals | - |
