MCX7-P-C-H-ST-CA3

Samtec, Inc.Samtec, Inc.
MCX7-P-C-H-ST-CA3 Image
Image may be representation. See specifications for product details.

Product Overview

Part Number: MCX7-P-C-H-ST-CA3
Manufacturer/Brand: Samtec, Inc.
Product description CONN MCX JACK STR 75 OHM SOLDER
Datasheets: 1.MCX7-P-C-H-ST-CA3.pdf2.MCX7-P-C-H-ST-CA3.pdf
RoHs Status Lead free / RoHS Compliant
Stock Condition 16490 pcs stock
Ship From Hong Kong
Shipment Way DHL/Fedex/TNT/UPS/EMS
In Stock 16490 pcs
Reference Price (In US Dollars)
1 pcs
$2.341
10 pcs
$2.243
25 pcs
$2.048
50 pcs
$1.951
100 pcs
$1.853
250 pcs
$1.658
500 pcs
$1.561
1000 pcs
$1.365
2500 pcs
$1.297
Request Quote
Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]
  • Target Price:
  • Qty:
Total:$2.341

Please give us your target price if quantities greater than those displayed.

  • Part Number
  • Company Name
  • Contact Name
  • E-mail
  • Message

Specifications of MCX7-P-C-H-ST-CA3

Part Number MCX7-P-C-H-ST-CA3 Manufacturer Samtec, Inc.
Description CONN MCX JACK STR 75 OHM SOLDER Lead Free Status / RoHS Status Lead free / RoHS Compliant
Quantity Available 16490 pcs Data sheet 1.MCX7-P-C-H-ST-CA3.pdf2.MCX7-P-C-H-ST-CA3.pdf
Voltage Rating 170V Shield Termination Crimp
Series TRUE75™ MCX7 Packaging Bulk
Other Names SAM9693 Operating Temperature -65°C ~ 125°C
Number of Ports 1 Mounting Type Free Hanging (In-Line)
Mounting Feature - Moisture Sensitivity Level (MSL) 1 (Unlimited)
Mating Cycles - Manufacturer Standard Lead Time 5 Weeks
Lead Free Status / RoHS Status Lead free / RoHS Compliant Insertion Loss -
Ingress Protection - Includes -
Impedance 75 Ohm Housing Color Gold
Frequency - Max 6GHz Features -
Fastening Type Snap-On Dielectric Material Polytetrafluoroethylene (PTFE)
Detailed Description MCX Connector Jack, Female Socket 75 Ohm Free Hanging (In-Line) Solder Contact Termination Solder
Connector Type Jack, Female Socket Connector Style MCX
Center Contact Plating Gold Center Contact Material Beryllium Copper
Cable Group RG-179 Body Material Brass
Body Finish Gold
