Phoenix Contact
| Part Number | 3273234 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | DISTRIBUTION BLOCK, BLOCK WITH H | Lead Free Status / RoHS Status | |
| Quantity Available | 17916 pcs | Data sheet | 3273234.pdf |
| Wire Gauge or Range - mm² | - | Wire Gauge or Range - AWG | 8-20 AWG |
| Voltage - UL | 600V | Voltage - IEC | 500V |
| Type | Middle | Termination Style | Push In, Spring |
| Terminal - Width | 40.6mm | Stripping Length | 12mm |
| Series | CLIPLINE PTFIX | Other Names | 277-15785 3273234-ND PTFIX 6/12X2 5-NS35A BK |
| Operating Temperature | - | Number of Positions | 13 |
| Number of Levels | 7 | Mounting Type | DIN Rail |
| Material Flammability Rating | UL94 V-0 | Material - Insulation | Polyamide (PA), Nylon |
| Manufacturer Standard Lead Time | 3 Weeks | Length | 1.799" (45.70mm) |
| Housing Color | Black | Height (Max) | 1.508" (38.30mm) |
| Features | - | Detailed Description | 13 Position Terminal Block Black Middle 40.6mm |
| Current - UL | 5A | Current - IEC | 24A |
