Phoenix Contact
| Part Number | 3212442 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLK PLUG 4POS 3.5MM BLUE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 28445 pcs | Data sheet | 3212442.pdf |
| Wire Gauge or Range - mm² | 0.14-1.5mm² | Wire Gauge or Range - AWG | 14-26 AWG |
| Voltage - UL | 300V | Voltage - IEC | 500V |
| Type | Plug Connection | Termination Style | Plug Receptacles, Push In, Spring |
| Terminal - Width | 3.5mm | Stripping Length | 8mm |
| Series | CLIPLINE PTTB | Other Names | 277-15362 3212442-ND PTTB1,5/S/2PBU PTTB15S2PBU |
| Operating Temperature | - | Number of Positions | 4 |
| Number of Levels | 2 | Mounting Type | DIN Rail |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polyamide (PA), Nylon | Manufacturer Standard Lead Time | 4 Weeks |
| Length | 2.728" (69.30mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Color | Blue | Height (Max) | 1.972" (50.10mm) |
| Features | - | Detailed Description | 4 Position Terminal Block Blue Plug Connection 3.5mm |
| Current - UL | 15A | Current - IEC | 16A |
