Phoenix Contact
| Part Number | 3121012 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLK GRND ISOL 2POS 22.5MM | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 990 pcs | Data sheet | 3121012.pdf |
| Wire Gauge or Range - mm² | 0.5-10mm² | Wire Gauge or Range - AWG | 8-26 AWG |
| Voltage - UL | 250V | Voltage - IEC | 110V |
| Type | Ground Isolating | Termination Style | Screw |
| Terminal - Width | 22.5mm | Stripping Length | 12mm |
| Series | CLIPLINE GTF | Other Names | 277-3880 3121012-ND GTF76/230 |
| Operating Temperature | - | Number of Positions | 2 |
| Number of Levels | 1 | Mounting Type | DIN Rail |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polyamide (PA), Nylon | Manufacturer Standard Lead Time | 4 Weeks |
| Length | 2.539" (64.50mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Color | Gray | Height (Max) | 2.421" (61.50mm) |
| Features | Indicators | Detailed Description | 2 Position Terminal Block Gray Ground Isolating 22.5mm |
| Current - UL | 50A | Current - IEC | 57A |
