Phoenix Contact
| Part Number | 3060296 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLK PLUG 4POS 6.2MM GRAY | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 36324 pcs | Data sheet | 1.3060296.pdf2.3060296.pdf |
| Wire Gauge or Range - mm² | 0.14-6mm² | Wire Gauge or Range - AWG | 10-26 AWG |
| Voltage - UL | 600V | Voltage - IEC | 500V |
| Type | Plug Connection | Termination Style | Plug Receptacles, Screw |
| Terminal - Width | 6.2mm | Stripping Length | 9mm |
| Series | CLIPLINE UT | Other Names | 277-15196 3060296-ND UT 4-QUATTRO/ 2P UT4-QUATTRO/2P |
| Operating Temperature | - | Number of Positions | 4 |
| Number of Levels | 1 | Mounting Type | DIN Rail |
| Material Flammability Rating | UL94 V-0 | Material - Insulation | Polyamide (PA), Nylon |
| Manufacturer Standard Lead Time | 2 Weeks | Length | 3.244" (82.40mm) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Housing Color | Gray |
| Height (Max) | 2.165" (55.00mm) | Features | - |
| Detailed Description | 4 Position Terminal Block Gray Plug Connection 6.2mm | Current - UL | 30A |
| Current - IEC | 32A |
