Phoenix Contact
| Part Number | 3058172 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLK NEMA 2POS 13.0MM GRAY | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 41252 pcs | Data sheet | 3058172.pdf |
| Wire Gauge or Range - mm² | 0.1-10mm² | Wire Gauge or Range - AWG | 8-26 AWG |
| Voltage - UL | 600V | Voltage - IEC | 800V |
| Type | NEMA Open Construction | Termination Style | Bolt and Nut |
| Terminal - Width | 13.0mm | Stripping Length | - |
| Series | CLIPLINE RSC | Other Names | 277-9603 3058172-ND RSC5-T |
| Operating Temperature | - | Number of Positions | 2 |
| Number of Levels | 1 | Mounting Type | Direct Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polyamide (PA), Nylon | Manufacturer Standard Lead Time | 2 Weeks |
| Length | 3.146" (79.90mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Color | Gray | Height (Max) | - |
| Features | Disconnect Point | Detailed Description | 2 Position Terminal Block Gray NEMA Open Construction 13.0mm |
| Current - UL | 45A | Current - IEC | 50A |
