Phoenix Contact
| Part Number | 3002034 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | TERM BLK PLUG 3POS 5.08MM GRAY | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 20961 pcs | Data sheet | 3002034.pdf |
| Wire Gauge or Range - mm² | 0.2-4mm² | Wire Gauge or Range - AWG | 12-30 AWG |
| Voltage - UL | 300V | Voltage - IEC | 250V |
| Type | Plug Connection | Termination Style | Plug Receptacles, Screw |
| Terminal - Width | 5.1mm | Stripping Length | 8mm |
| Series | CLIPLINE UK | Other Names | 277-3599 3002034-ND UK3-MSTB-5,08 |
| Operating Temperature | - | Number of Positions | 3 |
| Number of Levels | 2; Connected | Mounting Type | DIN Rail |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-2 |
| Material - Insulation | Polyamide (PA), Nylon | Manufacturer Standard Lead Time | 4 Weeks |
| Length | 1.673" (42.49mm) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Housing Color | Gray | Height (Max) | 2.146" (54.50mm) |
| Features | - | Detailed Description | 3 Position Terminal Block Gray Plug Connection 5.1mm |
| Current - UL | 20A | Current - IEC | 12A |
