Phoenix Contact
| Part Number | 2714035 | Manufacturer | Phoenix Contact |
|---|---|---|---|
| Description | CONN TERM BLK FEED THRU 12-28AWG | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 6597 pcs | Data sheet | |
| Wire Gauge or Range - mm² | 0.2-4mm² | Wire Gauge or Range - AWG | 12-28 AWG |
| Voltage - UL | 300V | Voltage - IEC | 400V |
| Type | Feed Through | Termination Style | Screw |
| Terminal - Width | 6.2mm | Stripping Length | 9mm |
| Series | CLIPLINE PIK | Other Names | 2714035-ND 277-4062 PIK 4-L/L PIK4-L/L |
| Number of Positions | 4 | Number of Levels | 2 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-2 |
| Material - Insulation | Polyamide (PA), Nylon | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Fuse Type | - | Features | - |
| Disconnect Type | - | Detailed Description | Terminal Block Connector 4 Position Feed Through Gray 12-28 AWG |
| Current - UL | 20A | Current - IEC | 32A |
| Color | Gray |
