Panasonic
| Part Number | EEE-FT1C680AR | Manufacturer | Panasonic |
|---|---|---|---|
| Description | CAP ALUM 68UF 20% 16V SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 659067 pcs | Data sheet | 1.EEE-FT1C680AR.pdf2.EEE-FT1C680AR.pdf3.EEE-FT1C680AR.pdf4.EEE-FT1C680AR.pdf5.EEE-FT1C680AR.pdf |
| Voltage - Rated | 16V | Tolerance | ±20% |
| Surface Mount Land Size | 0.209" L x 0.209" W (5.30mm x 5.30mm) | Size / Dimension | 0.197" Dia (5.00mm) |
| Series | FT | Ripple Current @ Low Frequency | 156mA @ 120Hz |
| Ripple Current @ High Frequency | 240mA @ 100kHz | Ratings | AEC-Q200 |
| Polarization | Polar | Packaging | Tape & Reel (TR) |
| Package / Case | Radial, Can - SMD | Other Names | EEEFT1C680AR P15091TR |
| Operating Temperature | -55°C ~ 105°C | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Manufacturer Standard Lead Time | 19 Weeks |
| Lifetime @ Temp. | 2000 Hrs @ 105°C | Lead Spacing | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height - Seated (Max) | 0.240" (6.10mm) |
| ESR (Equivalent Series Resistance) | 360 mOhm @ 100kHz | Detailed Description | 68µF 16V Aluminum Electrolytic Capacitors Radial, Can - SMD 360 mOhm @ 100kHz 2000 Hrs @ 105°C |
| Capacitance | 68µF | Applications | Automotive |
