Panasonic
| Part Number | CP1A-12V | Manufacturer | Panasonic |
|---|---|---|---|
| Description | RELAY AUTOMOTIVE SPST 20A 12V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 32531 pcs | Data sheet | CP1A-12V.pdf |
| Turn On Voltage (Max) | 7.2 VDC | Turn Off Voltage (Min) | 1 VDC |
| Termination Style | PC Pin | Switching Voltage | 14VDC - Nom |
| Series | CP | Release Time | 10ms |
| Packaging | Tube | Other Names | 255-1940 CP1A-12V-ND CP1A12V |
| Operating Temperature | -40°C ~ 85°C | Operate Time | 10ms |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Sealed - Fully | Contact Rating (Current) | 20A |
| Contact Material | Silver Alloy, Cadmium Free | Contact Form | SPST-NO (1 Form A) |
| Coil Voltage | 12VDC | Coil Type | Non Latching |
| Coil Resistance | 225 Ohms | Coil Power | 640 mW |
| Coil Current | 53.3mA |
