PUI Audio, Inc.
| Part Number | AS04004PO-R | Manufacturer | PUI Audio, Inc. |
|---|---|---|---|
| Description | SPEAKER 4OHM 2W TOP PORT 86DB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 16704 pcs | Data sheet | 1.AS04004PO-R.pdf2.AS04004PO-R.pdf |
| Type | General Purpose | Termination | Solder Eyelet(s) |
| Technology | Magnetic | Size / Dimension | 1.575" L x 1.118" W (40.00mm x 28.40mm) |
| Shape | Round, Rectangular Frame | Series | AS |
| Ratings | - | Power - Rated | 2W |
| Power - Max | 4W | Port Location | Top |
| Packaging | Tray | Other Names | 668-1358 688-1358 688-1358-ND AS04004PO-R-ND AS04004POR |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material - Magnet | Nd-Fe-B |
| Material - Cone | Paper | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Ingress Protection | - |
| Impedance | 4 Ohms | Height - Seated (Max) | 0.512" (13.00mm) |
| Frequency Range | 370Hz ~ 20kHz | Frequency - Self Resonant | 370Hz |
| Efficiency - dBA | 86.00 | Efficiency - Type | Sound Pressure Level (SPL) |
| Efficiency - Testing | 1W/500mm | Detailed Description | 4 Ohms General Purpose Speaker 2W 370Hz ~ 20kHz Top Round, Rectangular Frame 86dB |
