Omron
| Part Number | A6T-8104 | Manufacturer | Omron |
|---|---|---|---|
| Description | SWITCH SLIDE DIP SPST 25MA 24V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 47463 pcs | Data sheet | A6T-8104.pdf |
| Washable | No | Voltage Rating | 24VDC |
| Termination Style | PC Pin | Series | A6T |
| Pitch | 0.100" (2.54mm), Full | Packaging | Tube |
| Other Names | A6T-8104-ND A6T8104 SW1131 |
Operating Temperature | -20°C ~ 70°C |
| Number of Positions | 8 | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mechanical Life | 1,000 Cycles |
| Manufacturer Standard Lead Time | 16 Weeks | Length | 0.837" (21.26mm) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Height Above Board | 0.165" (4.20mm) |
| Features | - | Electrical Life | 1,000 Cycles |
| Detailed Description | Dip Switch SPST 8 Position Through Hole Slide (Standard) Actuator 25mA 24VDC | Current Rating | 25mA |
| Contact Material | - | Contact Finish | - |
| Circuit | SPST | Body Material | - |
| Actuator Type | Slide (Standard) | Actuator Level | Raised |
