Nexperia
| Part Number | BAV170QAZ | Manufacturer | Nexperia |
|---|---|---|---|
| Description | DIODE HS SW 75V 180MA 3DFN1010 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 308454 pcs | Data sheet | BAV170QAZ.pdf |
| Voltage - Forward (Vf) (Max) @ If | 1.25V @ 150mA | Voltage - DC Reverse (Vr) (Max) | 75V |
| Supplier Device Package | DFN1010D-3 | Speed | Small Signal =< 200mA (Io), Any Speed |
| Series | Automotive, AEC-Q101 | Reverse Recovery Time (trr) | 3µs |
| Packaging | Cut Tape (CT) | Package / Case | 3-XDFN Exposed Pad |
| Other Names | 1727-2553-1 568-12992-1 568-12992-1-ND |
Operating Temperature - Junction | 150°C (Max) |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Diode Type | Standard | Diode Configuration | 1 Pair Common Cathode |
| Detailed Description | Diode Array 1 Pair Common Cathode Standard 75V 180mA (DC) Surface Mount 3-XDFN Exposed Pad | Current - Reverse Leakage @ Vr | 5nA @ 75V |
| Current - Average Rectified (Io) (per Diode) | 180mA (DC) |
