NMB Technologies Corp.
| Part Number | 3108NL-04W-B19-L50 | Manufacturer | NMB Technologies Corp. |
|---|---|---|---|
| Description | FAN AXIAL 80X20MM 12VDC WIRE | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 16092 pcs | Data sheet | 1.3108NL-04W-B19-L50.pdf2.3108NL-04W-B19-L50.pdf3.3108NL-04W-B19-L50.pdf |
| Width | 20.00mm | Weight | 0.187 lb (84.82g) |
| Voltage Range | 6 ~ 13.8VDC | Voltage - Rated | 12VDC |
| Termination | 3 Wire Leads | Static Pressure | 0.084 in H2O (20.9 Pa) |
| Size / Dimension | Square - 80mm L x 80mm H | Series | 3108NL |
| RPM | 2350 RPM | Power (Watts) | 1.08W |
| Other Names | 08020MA-12J-AT-00 3108NL04WB19L50 3108NL04WB19L50-ND |
Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Noise | 26.0 dB | Material - Frame | Plastic |
| Material - Blade | Plastic | Manufacturer Standard Lead Time | 14 Weeks |
| Lifetime @ Temp. | - | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | - | Features | Speed Sensor (Tach) |
| Fan Type | Tubeaxial | Current Rating | 0.090A |
| Bearing Type | Ball | Approvals | CE, CSA, UL, VDE |
| Air Flow | 26.5 CFM (0.742m³/min) |
