NKK Switches
| Part Number | MS22AFW01 | Manufacturer | NKK Switches |
|---|---|---|---|
| Description | SWITCH SLIDE DPDT 6A 125V | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 17022 pcs | Data sheet | MS22AFW01.pdf |
| Voltage Rating - AC | 125V | Termination Style | Solder Lug |
| Switch Travel | 2.20mm | Switch Function | On-On |
| Series | MS | Packaging | Bulk |
| Other Names | 360-2382 360-2382-ND 360-3310 MS22AFW01-ND MS22AFW01-RO MS22AFW01-RO-ND |
Operating Temperature | -30°C ~ 85°C |
| Operating Force | - | Mounting Type | Panel Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Mechanical Life | 100,000 Cycles |
| Manufacturer Standard Lead Time | 7 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Epoxy Sealed Terminals | Electrical Life | 25,000 Cycles |
| Detailed Description | Slide Switch DPDT Panel Mount | Current Rating | 6A (AC) |
| Contact Timing | Non-Shorting (BBM) | Contact Material | Silver Alloy |
| Contact Finish | Silver | Circuit | DPDT |
| Actuator Type | Standard | Actuator Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Actuator Length | 5.10mm |
