LQH2MCN6R8M52L

Murata Electronics

Image may be representation. See specifications for product details.

Product Overview

Part Number:	LQH2MCN6R8M52L
Manufacturer/Brand:	Murata Electronics
Product description	FIXED IND 6.8UH 285MA 1.23 OHM
Datasheets:	1.LQH2MCN6R8M52L.pdf 2.LQH2MCN6R8M52L.pdf 3.LQH2MCN6R8M52L.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	734736 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 734736 pcs

Reference Price (In US Dollars)

3000 pcs: $0.051

6000 pcs: $0.048

15000 pcs: $0.047

30000 pcs: $0.045

75000 pcs: $0.044

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.051

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of LQH2MCN6R8M52L

Part Number	LQH2MCN6R8M52L	Manufacturer	Murata Electronics
Description	FIXED IND 6.8UH 285MA 1.23 OHM	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	734736 pcs	Data sheet	1.LQH2MCN6R8M52L.pdf 2.LQH2MCN6R8M52L.pdf 3.LQH2MCN6R8M52L.pdf
Type	Wirewound	Tolerance	±20%
Supplier Device Package	0806 (2016 Metric)	Size / Dimension	0.079" L x 0.063" W (2.00mm x 1.60mm)
Shielding	Unshielded	Series	LQH2
Ratings	-	Q @ Freq	-
Packaging	Tape & Reel (TR)	Package / Case	0806 (2016 Metric)
Other Names	490-4989-2	Operating Temperature	-40°C ~ 85°C
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	1 (Unlimited)
Material - Core	Ferrite	Manufacturer Standard Lead Time	10 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Inductance Frequency - Test	1MHz
Inductance	6.8µH	Height - Seated (Max)	0.037" (0.95mm)
Frequency - Self Resonant	65MHz	Detailed Description	6.8µH Unshielded Wirewound Inductor 285mA 1.6 Ohm Max 0806 (2016 Metric)
DC Resistance (DCR)	1.6 Ohm Max	Current Rating	285mA
Current - Saturation	-
