MEAN WELL
| Part Number | SDR-120-12 | Manufacturer | MEAN WELL |
|---|---|---|---|
| Description | AC/DC CONVERTER 12V 120W | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1717 pcs | Data sheet | SDR-120-12.pdf |
| Voltage - Output 4 | - | Voltage - Output 3 | - |
| Voltage - Output 2 | - | Voltage - Output 1 | 12V |
| Voltage - Isolation | 3kV | Voltage - Input | 88 ~ 264 VAC, 124 ~ 370 VDC |
| Type | Enclosed | Size / Dimension | 4.47" L x 1.57" W x 4.93" H (113.5mm x 40.0mm x 125.2mm) |
| Series | SDR-120 | Power (Watts) | 120W |
| Other Names | 1866-1078 SDR-120-12MW SDR-120-12MW-ND |
Operating Temperature | -25°C ~ 70°C (With Derating) |
| Number of Outputs | 1 | Mounting Type | DIN Rail |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Minimum Load Required | No |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Features | Adjustable Output, PFC, Universal Input | Efficiency | 89% |
| Detailed Description | Enclosed AC DC Converter 1 Output 12V 10A 88 ~ 264 VAC, 124 ~ 370 VDC Input | Current - Output (Max) | 10A |
| Approvals | CB, CE, cURus, TUV | Applications | Hazardous Locations, ITE (Commercial) |
