ART-B22-D300

LEM USA, Inc.

Image may be representation. See specifications for product details.

Product Overview

Part Number:	ART-B22-D300
Manufacturer/Brand:	LEM USA, Inc.
Product description	CURR SENSE XFMR FLEXIBLE COIL
Datasheets:	ART-B22-D300.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	543 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 543 pcs

Reference Price (In US Dollars)

1 pcs: $58.944

5 pcs: $52.394

10 pcs: $49.12

25 pcs: $47.482

50 pcs: $45.845

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$58.944

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of ART-B22-D300

Part Number	ART-B22-D300	Manufacturer	LEM USA, Inc.
Description	CURR SENSE XFMR FLEXIBLE COIL	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	543 pcs	Data sheet	ART-B22-D300.pdf
Type	Non-Invasive (Split Core)	Turns Ratio - Primary:Secondary	Rogowski Coil
Termination Style	Wire Leads	Size / Dimension	2.205" L x 1.326" W (56.01mm x 33.69mm)
Series	ART	Ratings	-
Other Names	398-1191 90.N3.99.000.0 ART B22 D300	Mounting Type	Free Hanging (In-Line)
Moisture Sensitivity Level (MSL)	1 (Unlimited)	Manufacturer Standard Lead Time	14 Weeks
Lead Free Status / RoHS Status	Lead free / RoHS Compliant	Inductance	566µH
Height - Seated (Max)	0.744" (18.91mm)	Frequency Range	50/60Hz
Energy Time (E.T.)	-	Detailed Description	Rogowski Coil Current Sense Transformer 50/60Hz 170 Ohm 566µH Free Hanging (In-Line)
DC Resistance (DCR)	170 Ohm	Current Ratio	-
