Knowles
| Part Number | SPV1840LR5H-B | Manufacturer | Knowles |
|---|---|---|---|
| Description | MIC MEMS ANALOG | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 259427 pcs | Data sheet | SPV1840LR5H-B.pdf |
| Voltage Range | 1.5V ~ 3.6V | Type | MEMS (Silicon) |
| Termination | Solder Pads | Size / Dimension | 0.108" L x 0.073" W (2.75mm x 1.85mm) |
| Shape | Rectangular | Series | SiSonic™, Zero-Height Mic™, SPV |
| Sensitivity | -38dB ±3dB @ 94dB SPL | S/N Ratio | 62.5dB |
| Port Location | Bottom | Packaging | Tape & Reel (TR) |
| Output Type | Analog | Other Names | 423-1397-2 KASKADE SPV1840LR5H-B-8 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Impedance | 400 Ohms | Height (Max) | 0.039" (0.98mm) |
| Frequency Range | 100Hz ~ 10kHz | Direction | Omnidirectional |
| Detailed Description | 100Hz ~ 10kHz Analog Microphone MEMS (Silicon) 1.5V ~ 3.6V Omnidirectional (-38dB ±3dB @ 94dB SPL) Solder Pads | Current - Supply | 60µA |
