International Rectifier (Infineon Technologies)
| Part Number | IRFH5302TR2PBF | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | MOSFET N-CH 30V 32A 5X6 PQFN | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 5133 pcs | Data sheet | IRFH5302TR2PBF.pdf |
| Vgs(th) (Max) @ Id | 2.35V @ 100µA | Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) | Supplier Device Package | PQFN (5x6) Single Die |
| Series | HEXFET® | Rds On (Max) @ Id, Vgs | 2.1 mOhm @ 50A, 10V |
| Power Dissipation (Max) | 3.6W (Ta), 100W (Tc) | Packaging | Original-Reel® |
| Package / Case | 8-PowerVDFN | Other Names | IRFH5302TR2PBFDKR |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 4400pF @ 15V | Gate Charge (Qg) (Max) @ Vgs | 76nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V | Drain to Source Voltage (Vdss) | 30V |
| Detailed Description | N-Channel 30V 32A (Ta), 100A (Tc) 3.6W (Ta), 100W (Tc) Surface Mount PQFN (5x6) Single Die | Current - Continuous Drain (Id) @ 25°C | 32A (Ta), 100A (Tc) |
