International Rectifier (Infineon Technologies)
| Part Number | IPB034N06N3GATMA1 | Manufacturer | International Rectifier (Infineon Technologies) |
|---|---|---|---|
| Description | MOSFET N-CH 60V 100A TO263-7 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 3847 pcs | Data sheet | IPB034N06N3GATMA1.pdf |
| Vgs(th) (Max) @ Id | 4V @ 93µA | Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) | Supplier Device Package | PG-TO263-7 |
| Series | OptiMOS™ | Rds On (Max) @ Id, Vgs | 3.4 mOhm @ 100A, 10V |
| Power Dissipation (Max) | 167W (Tc) | Packaging | Cut Tape (CT) |
| Package / Case | TO-263-7, D²Pak (6 Leads + Tab), TO-263CB | Other Names | IPB034N06N3 GCT IPB034N06N3 GCT-ND IPB034N06N3G IPB034N06N3GATMA1CT |
| Operating Temperature | -55°C ~ 175°C (TJ) | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 11000pF @ 30V | Gate Charge (Qg) (Max) @ Vgs | 130nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | Drain to Source Voltage (Vdss) | 60V |
| Detailed Description | N-Channel 60V 100A (Tc) 167W (Tc) Surface Mount PG-TO263-7 | Current - Continuous Drain (Id) @ 25°C | 100A (Tc) |
