Hirose
| Part Number | RM12BPE-6S(71) | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN PLUG FMALE 6POS SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 4630 pcs | Data sheet | RM12BPE-6S(71).pdf |
| Voltage Rating | 350VAC, 490VDC | Termination | Solder Cup |
| Shielding | - | Shell Size, MIL | - |
| Shell Size - Insert | 12 | Shell Material | Zinc Alloy |
| Shell Finish | Nickel | Series | RM |
| Packaging | Bulk | Other Names | *RM12BPE-6S(71) HR1739 RM12BPE6S71 |
| Orientation | Keyed | Operating Temperature | -25°C ~ 85°C |
| Number of Positions | 6 | Mounting Type | Free Hanging (In-Line) |
| Mounting Feature | - | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insert Material | Polyphenylene Sulfide (PPS) | Ingress Protection | - |
| Features | Backshell, Cable Clamp, Coupling Nut | Fastening Type | Bayonet Lock |
| Detailed Description | 6 Position Circular Connector Plug, Female Sockets Solder Cup Silver | Current Rating | 5A |
| Contact Material | Copper Alloy | Contact Finish Thickness - Mating | 196.9µin (5.00µm) |
| Contact Finish - Mating | Silver | Connector Type | Plug, Female Sockets |
| Color | Silver | Cable Opening | 0.197" ~ 0.315" (5.00mm ~ 8.00mm) |
| Backshell Material, Plating | Zinc Alloy, Nickel | Applications | - |
