Hirose
| Part Number | MXR-8R-4SA(71) | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN RCPT FMALE 4POS GOLD SOLDER | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 9080 pcs | Data sheet | MXR-8R-4SA(71).pdf |
| Voltage Rating | 100VAC, 140VDC | Termination | Solder |
| Shielding | - | Shell Size, MIL | - |
| Shell Size - Insert | 8 | Shell Material | Aluminum Alloy |
| Shell Finish | Nickel | Series | MXR |
| Packaging | Bulk | Other Names | *MXR-8R-4SA(71) HR1831 MXR8R4SA71 |
| Orientation | Keyed | Operating Temperature | -25°C ~ 85°C |
| Number of Positions | 4 | Mounting Type | Panel Mount, Through Hole |
| Mounting Feature | Flange | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Manufacturer Standard Lead Time | 12 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Insert Material | Polybutylene Terephthalate (PBT) |
| Ingress Protection | - | Features | Board Guide, Ground |
| Fastening Type | Push-Pull | Detailed Description | 4 Position Circular Connector Receptacle, Female Sockets Solder Gold |
| Current Rating | 2A | Contact Material | Phosphor Bronze |
| Contact Finish Thickness - Mating | 8.00µin (0.203µm) | Contact Finish - Mating | Gold |
| Connector Type | Receptacle, Female Sockets | Color | Silver |
| Cable Opening | - | Backshell Material, Plating | - |
| Applications | - |
