Hirose
| Part Number | MRF18-8R-PC | Manufacturer | Hirose |
|---|---|---|---|
| Description | CONN RECEPT 8POS PCB | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2610 pcs | Data sheet | MRF18-8R-PC.pdf |
| Voltage Rating | - | Termination | Solder |
| Style | - | Series | MRF18 |
| Row Spacing - Mating | - | Pitch - Mating | - |
| Packaging | Bulk | Other Names | H124208 MRF18-8R-PC-ND |
| Operating Temperature | -40°C ~ 125°C | Number of Rows | 1 |
| Number of Positions Loaded | All | Number of Positions | 8 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 | Mated Stacking Heights | - |
| Manufacturer Standard Lead Time | 16 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Insulation Material | Polyamide (PA), Nylon | Insulation Height | 0.250" (6.35mm) |
| Insulation Color | Black | Ingress Protection | - |
| Features | Board Lock | Fastening Type | Latch Holder |
| Detailed Description | 8 Position Receptacle Connector Through Hole | Current Rating | - |
| Contact Type | Female Blade Socket | Contact Shape | Rectangular |
| Contact Material | Brass | Contact Length - Post | 0.091" (2.30mm) |
| Contact Finish Thickness - Post | - | Contact Finish Thickness - Mating | - |
| Contact Finish - Post | Tin | Contact Finish - Mating | Gold |
| Connector Type | Receptacle | Applications | - |
