Hamlin / Littelfuse
| Part Number | NANOSMDM075-2 | Manufacturer | Hamlin / Littelfuse |
|---|---|---|---|
| Description | PTC RESET FUSE 6V 750MA 1206 | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 3231 pcs | Data sheet | 1.NANOSMDM075-2.pdf2.NANOSMDM075-2.pdf |
| Voltage - Max | 6V | Type | Polymeric |
| Time to Trip | 200ms | Thickness (Max) | 0.047" (1.20mm) |
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.59mm) | Series | PolySwitch®, nanoSMD |
| Resistance - Post Trip (R1) (Max) | 290 mOhms | Resistance - Initial (Ri) (Min) | 100 mOhms |
| Ratings | - | Packaging | Cut Tape (CT) |
| Package / Case | 1206 (3216 Metric), Concave | Other Names | NANOSMDM075-2CT NANOSMDM0752 NANOSMDM075CT NANOSMDM075CT-ND |
| Operating Temperature | - | Mounting Type | Surface Mount |
| Moisture Sensitivity Level (MSL) | 2A (4 Weeks) | Lead Spacing | - |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | Height - Seated (Max) | - |
| Detailed Description | Polymeric PTC Resettable Fuse 6V 750mA Ih Surface Mount 1206 (3216 Metric), Concave | Current - Trip (It) | 1.5A |
| Current - Max | 40A | Current - Hold (Ih) (Max) | 750mA |
| Approvals | CSA, TUV, UL |
