Global Power Technologies Group
| Part Number | GP1M008A080H | Manufacturer | Global Power Technologies Group |
|---|---|---|---|
| Description | MOSFET N-CH 800V 8A TO220 | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2786 pcs | Data sheet | GP1M008A080H.pdf |
| Vgs(th) (Max) @ Id | 4V @ 250µA | Vgs (Max) | ±30V |
| Technology | MOSFET (Metal Oxide) | Supplier Device Package | TO-220 |
| Series | - | Rds On (Max) @ Id, Vgs | 1.4 Ohm @ 4A, 10V |
| Power Dissipation (Max) | 250W (Tc) | Packaging | Tube |
| Package / Case | TO-220-3 | Other Names | 1560-1170-1 1560-1170-1-ND 1560-1170-5 |
| Operating Temperature | -55°C ~ 150°C (TJ) | Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 1921pF @ 25V | Gate Charge (Qg) (Max) @ Vgs | 46nC @ 10V |
| FET Type | N-Channel | FET Feature | - |
| Drive Voltage (Max Rds On, Min Rds On) | 10V | Drain to Source Voltage (Vdss) | 800V |
| Detailed Description | N-Channel 800V 8A (Tc) 250W (Tc) Through Hole TO-220 | Current - Continuous Drain (Id) @ 25°C | 8A (Tc) |
