Conxall / Switchcraft
| Part Number | 153X | Manufacturer | Conxall / Switchcraft |
|---|---|---|---|
| Description | CONN JACK MONO 6.35MM PNL MNT | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1911 pcs | Data sheet | 1.153X.pdf2.153X.pdf |
| Voltage - Rated | 48VDC | Thread Size | 9/16-12 UNC |
| Termination | Solder Eyelet(s) | Signal Lines | Mono |
| Shielding | Unshielded | Series | E |
| Panel Hole Size | - | Packaging | Bulk |
| Other Names | 153 153-ND |
Operating Temperature | - |
| Number of Positions/Contacts | 2 Conductors, 2 Contacts | Mounting Type | Panel Mount |
| Moisture Sensitivity Level (MSL) | Not Applicable | Mating Length/Depth | - |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Internal Switch(s) | Does Not Contain Switch | Insulation Color | - |
| Industry Recognized Mating Diameter | 6.35mm (0.250", 1/4") - Headphone | Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
| Housing Material | - | Gender | Female |
| Features | Mounting Hardware, Thread Lock | Detailed Description | 6.35mm (0.250", 1/4") - Headphone Phone Jack Mono Connector Solder Eyelet(s) |
| Current Rating | 250mA | Contact Material - Plating | Silver |
| Contact Material | Copper Alloy | Connector Type | Phone Jack |
| Cable Opening | - | Body Material | Brass |
| Body Color | Silver | Actual Diameter | 0.250" (6.35mm) |
