Conec
| Part Number | 15-002253 | Manufacturer | Conec |
|---|---|---|---|
| Description | CONN DSUB HD RCPT 26POS R/A SLDR | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 2947 pcs | Data sheet | 15-002253.pdf |
| Wire Gauge | - | Voltage Rating | 60V |
| Termination | Solder | Shell Size, Connector Layout | 2 (DA, A) High Density |
| Shell Material, Finish | Zinc Die Cast, Nickel Plated | Series | - |
| Packaging | Bulk | Other Names | 15002253 626-1459 |
| Operating Temperature | -25°C ~ 105°C | Number of Rows | 3 |
| Number of Positions | 26 | Mounting Type | Board Edge, Through Hole, Right Angle |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | Material Flammability Rating | UL94 V-0 |
| Manufacturer Standard Lead Time | 12 Weeks | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Ingress Protection | IP67 - Dust Tight, Waterproof | Housing Material | Polybutylene Terephthalate (PBT), Glass Filled |
| Flange Feature | Mating Side, Female Screwlock (4-40) | Features | Board Lock, Mounting Brackets |
| Detailed Description | 26 Position D-Sub, High Density Receptacle, Female Sockets Connector | Current Rating | 3A |
| Contact Type | Signal | Contact Material | Copper Alloy |
| Contact Form | - | Contact Finish Thickness | 8.00µin (0.203µm) |
| Contact Finish | Gold | Connector Type | Receptacle, Female Sockets |
| Connector Style | D-Sub, High Density | Color | Black |
| Backset Spacing | 0.220" (5.60mm) |
