CL-505S-X-SD-T

Citizen Electronics Co., Ltd.

Image may be representation. See specifications for product details.

Product Overview

Part Number:	CL-505S-X-SD-T
Manufacturer/Brand:	Citizen Electronics Co., Ltd.
Product description	LED TRI TOP FIRING 1.0 X 1.0
Datasheets:	CL-505S-X-SD-T.pdf
RoHs Status	Lead free / RoHS Compliant
Stock Condition	440725 pcs stock
Ship From	Hong Kong
Shipment Way	DHL/Fedex/TNT/UPS/EMS

In Stock 440725 pcs

Reference Price (In US Dollars)

5000 pcs: $0.084

10000 pcs: $0.082

25000 pcs: $0.081

Request Quote: Please complete all required fields with your contact information.Click "SUBMIT RFQ" we will contact you shortly by email. Or Email us:[email protected]

Target Price:(USD)
Qty:

Total:$0.084

Please give us your target price if quantities greater than those displayed.

Part Number
Company Name
Contact Name
E-mail
Message

Specifications of CL-505S-X-SD-T

Part Number	CL-505S-X-SD-T	Manufacturer	Citizen Electronics Co., Ltd.
Description	LED TRI TOP FIRING 1.0 X 1.0	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Quantity Available	440725 pcs	Data sheet	CL-505S-X-SD-T.pdf
Wavelength - Peak	-	Wavelength - Dominant	615nm Red, 530nm Green, 470nm Blue
Voltage - Forward (Vf) (Typ)	1.85V Red, 2.7V Green, 2.75V Blue	Viewing Angle	-
Supplier Device Package	-	Size / Dimension	1.00mm L x 1.00mm W
Series	CL-505S	Packaging	Tape & Reel (TR)
Package / Case	0404 (1010 Metric)	Other Names	1642-1510-2 CL-505S-X-SD
Mounting Type	Surface Mount	Moisture Sensitivity Level (MSL)	3 (168 Hours)
Millicandela Rating	40mcd Red, 220mcd Green, 65mcd Blue	Manufacturer Standard Lead Time	8 Weeks
Lens Transparency	-	Lens Style/Size	Square with Flat Top, 1.00mm
Lens Color	-	Lead Free Status / RoHS Status	Lead free / RoHS Compliant
Height (Max)	0.26mm	Features	-
Detailed Description	Red, Green, Blue (RGB) 615nm Red, 530nm Green, 470nm Blue LED Indication - Discrete 1.85V Red, 2.7V Green, 2.75V Blue 0404 (1010 Metric)	Current - Test	5mA Red, 5mA Green, 5mA Blue
Configuration	Common Anode	Color	Red, Green, Blue (RGB)
