Bourns, Inc.
| Part Number | SDR1307-100ML | Manufacturer | Bourns, Inc. |
|---|---|---|---|
| Description | FIXED IND 10UH 5.6A 21 MOHM SMD | Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 172657 pcs | Data sheet | SDR1307-100ML.pdf |
| Type | Wirewound | Tolerance | ±20% |
| Supplier Device Package | - | Size / Dimension | 0.512" L x 0.512" W (13.00mm x 13.00mm) |
| Shielding | Unshielded | Series | SDR1307 |
| Ratings | - | Q @ Freq | 22 @ 2.52MHz |
| Packaging | Tape & Reel (TR) | Package / Case | Nonstandard |
| Other Names | SDR1307-100ML-ND SDR1307-100MLTR SDR1307100ML |
Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Material - Core | Ferrite | Manufacturer Standard Lead Time | 16 Weeks |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | Inductance Frequency - Test | 100kHz |
| Inductance | 10µH | Height - Seated (Max) | 0.287" (7.30mm) |
| Frequency - Self Resonant | 22MHz | Detailed Description | 10µH Unshielded Wirewound Inductor 5.6A 21 mOhm Max Nonstandard |
| DC Resistance (DCR) | 21 mOhm Max | Current Rating | 5.6A |
| Current - Saturation | 9.2A |
