Avago Technologies (Broadcom Limited)
| Part Number | HCPL-3150 | Manufacturer | Avago Technologies (Broadcom Limited) |
|---|---|---|---|
| Description | OPTOISO 3.75KV 1CH GATE DVR 8DIP | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Quantity Available | 25422 pcs | Data sheet | HCPL-3150.pdf |
| Voltage - Supply | 15 V ~ 30 V | Voltage - Isolation | 3750Vrms |
| Voltage - Forward (Vf) (Typ) | 1.5V | Technology | Optical Coupling |
| Supplier Device Package | 8-DIP | Series | - |
| Rise / Fall Time (Typ) | 100ns, 100ns | Pulse Width Distortion (Max) | 300ns |
| Propagation Delay tpLH / tpHL (Max) | 500ns, 500ns | Packaging | Tube |
| Package / Case | 8-DIP (0.300", 7.62mm) | Other Names | 516-1125-5 HCPL3150 |
| Operating Temperature | -40°C ~ 100°C | Number of Channels | 1 |
| Mounting Type | Through Hole | Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 8 Weeks | Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Detailed Description | 600mA Gate Driver Optical Coupling 3750Vrms 1 Channel 8-DIP | Current - Peak Output | 600mA |
| Current - Output High, Low | 500mA, 500mA | Current - DC Forward (If) (Max) | 25mA |
| Common Mode Transient Immunity (Min) | 15kV/µs | Approvals | CSA, UR |
